Name: ANDRITZ Single-stage Centrifugal Pumps S Series
Brand: Shijiazhuang First Pump Factory Co., Ltd.

ANDRITZ Single-stage Centrifugal Pumps S Series

Engineered for the rigorous demands of the pulp and paper industry, the S Series of single-stage centrifugal pumps delivers unwavering reliability in handling a spectrum of media, from clean filtrates to abrasive paper stocks. These pumps are purpose-built to ensure continuous operation in critical processes, focusing on maximum uptime, ease of service, and resistance to the challenging conditions of mill environments.

Core Design Philosophy: Serviceability and Durability

A key advantage of this pump series is its user-centric design, which prioritizes operational economy over its entire lifecycle.

Maintenance-optimized Architecture: The pumps feature a back pull-out design. This allows for the entire rotating assembly—including the impeller, shaft, and bearings—to be removed quickly and easily without disturbing the pump casing or the connected piping. This drastically reduces maintenance time and labor costs.
Application-Tailored Impeller Selection: The series offers a choice of open, semi-open, or closed impellers. The open impeller design is particularly effective for stock with suspended solids, minimizing clogging and reducing axial thrust, while other designs optimize efficiency for cleaner or more abrasive media.
Robust Sealing Solutions: A modular sealing chamber accommodates a wide array of sealing arrangements, from standard gland packings to advanced single, double, and cartridge mechanical seals. This flexibility ensures the perfect seal for any specific duty, whether handling hot water, aggressive chemicals, or fibrous slurries.
Engineered for Longevity: Critical wet-end components are available in a range of wear-resistant materials, including various grades of stainless steel, duplex, and super duplex alloys, to combat corrosion and erosion, thereby extending service intervals.

Technical Specifications of ANDRITZ Single-stage Centrifugal Pumps S Series

Flow Rate	Up to 8,000 m³/h
Head	10–180 m
Pressure	Up to 40 bar
Temperature Range	-20°C to +200°C
Consistency	Up to 8% solids content
Efficiency	Up to 90%, with low NPSH requirements.
Certifications	ATEX compliance for hazardous environments.

Performance and Application Scope of ANDRITZ Single-stage Centrifugal Pumps S Series

The S Series is capable of handling high flow rates and developed heads, making it suitable for the most demanding positions in a mill. Its operational window supports temperatures from sub-zero levels up to +200°C and can manage media with solid contents, ensuring versatility across the production line.

Primary applications within the pulp and paper industry include:

High-consistency stock transfer and feeding
Recycled fiber processing and broke handling
Chemical additive and coating circulation
Filtrate water and white water systems
Effluent and wastewater treatment circuits

The S Series Paper Pulp Pumps stand as a testament to advanced hydraulic engineering and practical design. By combining a maintenance-friendly structure with a highly configurable build and wear-resistant materials, this pump series offers a dependable, cost-effective solution for maintaining peak productivity in the challenging environments of modern pulp and paper production.
