Name: ANDRITZ Single-stage Centrifugal Pumps VP Series
Brand: Shijiazhuang First Pump Factory Co., Ltd.

ANDRITZ Single-stage Centrifugal Pumps VP Series

Engineered for the most demanding applications in the pulp and paper industry, the VP Series of single-stage centrifugal pumps sets a new standard for reliability and efficiency in handling fibrous, abrasive, and solid-laden media. These robust pumps are specifically designed to minimize clogging and reduce energy consumption, delivering superior performance in harsh processing environments.

Versatile Industrial Applications of ANDRITZ Single-stage Centrifugal Pumps VP Series

The VP Series is built to perform across a wide spectrum of industries and applications, including:

Pulp & Paper Production: Raw pulp, paper stock, wastepaper slurry, and alkali recovery streams.
Chemical & Pharmaceutical Processing: Chemical slurries, pharmaceutical intermediates, and abrasive process fluids.
Water & Wastewater Management: Effluent treatment, sludge transfer, and water supply.
Food & Bio-Products: Handling molasses, sugar syrups, and other viscous food products.
Fertilizer & Mining: Potash fertilizer slurries, coal preparation, and other mineral processing duties.

Uncompromising Design for Demanding Applications of ANDRITZ Single-stage Centrifugal Pumps VP Series

The VP Series incorporates several key design features to ensure continuous, trouble-free operation:

Advanced Impeller Design: A precision-cast, semi-open impeller with a large, non-clog channel and 3-6 vanes efficiently handles high concentrations of fibrous material. This design minimizes axial force, prevents air entrainment, and is ideal for pumping pulp, paper stock, and waste paper.
Optimized Volute Casing: The single-stage, double-volute casing structure is engineered to significantly reduce radial forces and shaft deflection, enhancing bearing life and overall mechanical stability.
Robust Material Selection: Wetted components are available in a range of durable materials including cast iron, stainless steel (304, 316L), and duplex stainless steels to resist corrosion and abrasion, ensuring a long service life.
Flexible Sealing Solutions: The pumps support various sealing arrangements, including single and double mechanical seals or traditional packing, to suit specific process requirements and minimize leakage.
Modular & Service-Friendly Construction: A innovative modular design minimizes the number of necessary spare parts, streamlining inventory and reducing maintenance downtime. The sealing arrangement allows for easy access and repair.

Key Specifications & Operational Benefits of ANDRITZ Single-stage Centrifugal Pumps VP Series

Design	single-stage, single-flow; semi-open vortex impeller
Head	up to 75 m
Flow Rate	up to 1,800 m3 /h
Free Passage	up to 140 mm
Pressure	up to 16 bar
Temperature	up to 120° C
Hydraulic Efficiency	Achieves up to 90% maximum efficiency, lowering operational costs.
Superior NPSH Performance	State-of-the-art hydraulic design provides excellent Net Positive Suction Head characteristics.
Excellent Part-Load Operation	Maintains stable performance even at off-peak operating conditions, surpassing typical industry benchmarks.

Ideal for Handling:

Paper Pulp
Paper Stock
Waste Paper Stock
Chemical Slurries
Effluent and Wastewater
Solids-Containing Fluids

With their robust construction, energy-efficient operation, and proven ability to handle challenging fibrous materials without clogging, the VP Series Centrifugal Pumps are the intelligent choice for boosting productivity and reliability in your critical pumping processes.
